Aperçu technique
Kit cadre
Cadre:
SCOR 4060 Z Full Carbon Frame | Lower-Link Driven Instant Center Linkage | 140 / 160mm Rear Travel | Fully Guided Internal Cable Routing | Boost 148 | SRAM UDH
Fourche:
RockShox ZEB Select RC | 170mm Travel | 44mm Rake
Suspension
Suspension Avant:
RockShox ZEB Select RC | 170mm Travel | 44mm Rake
Suspension Arrière:
RockShox Super Deluxe Select | Rebound adjust
E-System
Unité Moteur:
SHIMANO Steps EP8 DU-EP800
Batterie:
Darfon 36V | SHIMANO Steps service included | 720 Wh
Écran:
SHIMANO Steps EP8 Wireless Cycle Computer SC-EM800
Commande d'Assistance:
SHIMANO Steps EP8 Left Switch Unit SW-EM800-L
Chargeur:
Darfon Smart Plus 100-240V | 4A | EU
Cockpit
Potence:
SCOR Alloy Stem | 3D Forged | 31.6mm Bar Bore | 35mm Length | 0° Angle
Cintre:
SCOR Alloy Bar | 31.8mm Clamp | 800mm Wide | 20mm Rise | 5° Upsweep | 9° Backsweep
Grips / Guidoline:
VP VPG-125A
Seat
Tige de Selle:
X-Fusion Manic | S 125mm | M 150mm | L / XL 170mm Travel
Selle:
Fizik Terra Alpaca X5
Transmission
Pédalier:
SHIMANO FC-EM600 | 165mm Length
Plateaux:
34T
Cassette:
SHIMANO Deore CS-M6100-12
Taille de cassette:
10-51T
Chaîne:
SHIMANO CN-M6100
Dérailleur Arrière:
SHIMANO Deore SLX RD-M7100
Leviers de Vitesses:
SHIMANO Deore SLX SL-M7100-R
Vitesses:
1 x 12
Freins
Leviers de Frein / Étriers:
SHIMANO Deore | BL-M6100 Levers | BR-M6120 Calipers
Disques:
SHIMANO SM-RT66
Largeur de Pedalier:
203mm
Roues
Jantes:
XDH-130 | 32 Spokes | 6061-T6 Alloy | Welded Joint | 30mm Internal Width | Tubeless ready
Moyeux:
XDH-130 | 32 Spokes | Sealed Cartridge Bearings
Pneus:
Maxxis Assegai 29 x 2.5" 3C MaxxGrip Exo+ TR (F) | Maxxis Dissector 29 x 2.4" 3C MaxxTerra DD TR (R)
Information Tubeless:
Tubeless Ready Rims | Tubetype Tires
Informations supplémentaires
Reifenfreiheit:
Width: 64mm | Diameter: 750mm
Gewicht ohne Pedale:
22.80kg
ASTM-Klassifizierung:
Level 4
Maximales Systemgewicht:
130kg
Règlement relatif à la sécurité générale des produits (GPSR):
Consignes de sécurité GPSR (UE)
Personne responsable conformément au GPSR (UE)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | 155 - 170 | 165 - 180 | 175 - 190 | 185 - 200 |
| BB Drop (SLACK) | 19 | 19 | 19 | 19 |
| BB Drop (STEEP) | 16 | 16 | 16 | 16 |
| BB Height (SLACK) | 350 | 350 | 350 | 350 |
| BB Height (STEEP) | 353 | 353 | 353 | 353 |
| Chainstay | 435 | 435 | 435 | 435 |
| Fork Length | 580 | 580 | 580 | 580 |
| Fork Rake | 44 | 44 | 44 | 44 |
| Front Center (SLACK) | 773 | 798 | 823 | 853 |
| Front Center (STEEP) | 761 | 785 | 810 | 840 |
| Head Tube | 87 | 99 | 115 | 127 |
| HT Angle (SLACK) | 63.8 | 63.8 | 63.8 | 63.8 |
| HT Angle (STEEP) | 65 | 65 | 65 | 65 |
| Reach (SLACK) | 435 | 459 | 485 | 515 |
| Reach (STEEP) | 431 | 456 | 481 | 511 |
| Seat Tube | 400 | 425 | 440 | 470 |
| ST Angle @750mm Saddle Height (SLACK) | 76.5 | 76.5 | 76.5 | 76.5 |
| ST Angle @750mm Saddle Height (STEEP) | 76 | 76 | 76 | 76 |
| ST Angle Actual (SLACK) | 69 | 69 | 69 | 69 |
| ST Angle Actual (STEEP) | 68.5 | 68.5 | 68.5 | 68.5 |
| ST Angle Effective (SLACK) | 77.9 | 77.9 | 77.9 | 77.9 |
| ST Angle Effective (STEEP) | 77.4 | 77.4 | 77.4 | 77.4 |
| Stack (SLACK) | 601 | 612 | 626 | 637 |
| Stack (STEEP) | 603 | 615 | 629 | 640 |
| Stand Over Height (80 in Front of BB) | 759 | 771 | 775 | 791 |
| Stand Over Height (Lowest Point) | 722 | 731 | 739 | 749 |
| Top Tube (SLACK) | 562 | 590 | 621 | 655 |
| Top Tube (STEEP) | 564 | 592 | 623 | 657 |
| Wheelbase (SLACK) | 1206 | 1230 | 1255 | 1285 |
| Wheelbase (STEEP) | 1193 | 1217 | 1242 | 1272 |
